变频器型号

输入电压

额定容量(KVA)

额定输入电流(A)

额定输出电流(A)

适配电机(KW)

ACD500-4T0.7

三相380V范围：-15%~20%

1.5

3.4

2.1

0.75

ACD500-4T1.5

3.0

5.0

3.8

1.5

ACD500-4T2.2

4.0

5.8

5.1

2.2

ACD500-4T4.0

5.9

10.5

9.0

4.0

ACD500-4T5.5

8.9

14.6

13.0

5.5

ACD500-4T7.5

11.0

20.5

17.0

7.5

ACD500-4T11

17.0

26.0

25.0

11

ACD500-4T15

21.0

35.0

32.0

15

ACD500-4T18.5

24.0

38.5

37.0

18.5

ACD500-4T22

30.0

46.5

45.0

22

ACD500-4T30

40.0

62.0

60.0

30

ACD500-4T37

57.0

76.0

75.0

37

ACD500-4T45

69.0

92.0

91.0

45

ACD500-4T55

85.0

113.0

112.0

55

ACD500-4T75

114.0

157.0

150.0

75

ACD500-4T90

134.0

180.0

176.0

90

ACD500-4T110

160.0

214.0

210.0

110

ACD500-4T132

192.0

256.0

253.0

132

ACD500-4T160

231.0

307.0

304.0

160

ACD500-4T200

250.0

385.0

377.0

200

ACD500-4T220

280.0

430.0

426.0

220

ACD500-4T250

355.0

468.0

465.0

250

ACD500-4T280

396.0

525.0

520.0

280

ACD500-4T315

445.0

590.0

585.0

315

ACD500-4T355

500.0

665.0

650.0

355

ACD500-4T400

565.0

785.0

725.0

400

ACD500-4T450

630.0

883.0

820.0

450

壳体

规格型号

尺寸(mm)

A

B

H

W

D

d

塑

壳

壳

体

E22

ACD500-4T0.7GB

118.0

172.5

185.0

105.5

150.0

5.0

ACD500-4T1.5GB

ACD500-4T2.2Gb

ACD500-3.0GB/4.0LB

118.0

172.5

185.0

105.5

150.0

5.0

ACD500-4T4.0GB

E75

ACD500-4T5.5LB

160.0

172.0

185.0

105.0

170.0

5.0

ACD500-4T5.5GB/7.5LB

ACD500-4T7.5GB

壁

挂

式

金

属

机

箱

E011

ACD500-4T11LB

210.0

322.0

336.0

150.0

200.0

7.0

ACD500-4T11GB/15LB

ACD500-4T15GB/18.5LB

T030

ACD500-4T18.5G/22L

285.0

457.0

475.0

195.0

240.0

9.0

ACD500-4T22G/30L

ACD500-4T30G/37L

E018

ACD500-4T18.5G/22L

290.0

429.0

455.0

274.0

230.0

6

ACD500-4T22G/30L

ACD500-4T30G/37L

E037

ACD500-4T37G/45L

320.0

536.0

555.0

230.0

228.8

10.0

ACD500-4T45G/55L

E055

ACD500-4T55G/75L

410.0

611.0

634.0

320.0

236.1

12.0

ACD500-4T75G/90L

壁挂式金属机箱

T090

ACD500-4T55G/75L

375.0

725.0

750.0

290.0

335.0

13.0

ACD500-4T75G/90L

ACD500-4T90G/110L

挂式柜式一体机

E090

ACD500-4T90G/110L

460

631

H1:588

320

343

12

ACD500-4T110G/132L

H2:988

E132

ACD500-4T110G/132L

500

765.0

H1:790.0

400.0

340.0

11.0

ACD500-4T132G/160L

H2:1130.0

立体式金属机箱

K200

ACD500-4T160G/185L

685.0

-

1400.0

-

440.0

-

ACD500-4T185G/200L

ACD500-4T200G/220L

挂式柜式一体机

E185

ACD500-4T132G/160L

561

823

H1:847

420

350

14

ACD500-4T160G/185L

ACD500-4T185G/200L

H2:1141

ACD500-4T200G/220L

立体式金属机箱

K400

ACD500-4T220G/250L

800.0

-

1600.0

-

550.0

-

ACD500-4T250G/280L

ACD500-4T280G/315L

ACD500-4T315G/355L

ACD500-4T355G/400L

ACD500-4T400G/450L

挂

式

柜

式

一

体

机

E220

ACD500-4T220G/250L

740

930

H1:956

520

377

14

ACD500-4T250G/280L

H2:1356

ACD500-4T280G/315L

E355

ACD500-4T315G/355L

820

1188

H1:1232

620

381

18

ACD500-4T355G/400L

ACD500-4T400G/450L

H2:1618.5
